RAL 7035 IP 65 metal carpentry
general switch with door interlock
single-phase power supply 230V 50760 Hz
powers up to 1.5 kW
transformer for 24 Vac auxiliary circuit
primary and secondary protection fuses
contactors for starting motors
motor protections with magnetothermic motor protectors
daily clock compressor shutdown at night
MAN-0-AUT control selectors, pumps running
MAN-0-AUT control selectors, compressor running
electronic relay alternation pumps
parallel running pumps
voltage presence indicator
gear and engine advance warning lights
alarm silence button
terminals for connection of 4 pressure switches
pressure switch to stop pumps
A2C-E-M-01-H-M-I

Specific References

Schema
6913R0

Download

SCHEMA A2CE-M

Download (515.04k)
